Manual Stacker LIFT-M for 1,6m

Manual Stacker LIFT-M for 1,6m

It is low-maintenance, durable and strong - even in terms of price.
– 5 %
1.199,00 €
1.139,00 € excl. VAT
5
Five year warranty

Free delivery: Wednesday, 19 March

📢 In use by 5162+ companies across Europe

SKU 10000902-82

Questions? We’re here to help you

+498123 900 88 90

Our LIFT-M is a manual high lift truck with a lifting height of 1.6 metres. It is ideal for stacking Euro pallets or loading and unloading trucks. Compact in design, it shows its strengths in small and medium-sized companies.

  • Load capacity: Choose between 1,000 kg or 1,500 kg maximum load capacity
  • Free lift: Lift pallets up to 1,600 mm without changing the overall height
  • Height: It fits through many doors with a minimum total height of 1,970 mm as LIFT-M with 1,000 kg or 2,080 mm as LIFT-M with 1,500 kg
  • Turning radius: Easy to maneuver in tight spaces with just 1,380 mm
  • Operation: Lift loads comfortably using the foot pedal or by pumping the drawbar
  • Fork length: The standard length 1,150 mm is ideal for Euro pallets and lattice boxes
  • Load rollers: Easily overcome small uneven ground with the tandem tires of the rollers
  • Maintenance: Low maintenance effort due to permanently lubricated ball bearings
  • Use: The LIFT-M helps with loading and unloading trucks and stacking pallets

Features

LIFT series

The LIFT series

LIFT hydraulic stackers are reduced to the essentials – this makes them easy to maintain, durable and affordable. They are available in different lifting heights.

Raise and lower

the loads to the desired height using the foot pedal or by pumping the drawbar. The loads can be lowered continuously using the hand lever on the drawbar.
hand stacker 1,2m image 18

High-quality frame

LIFT hand pallet trucks have a torsion-resistant industrial steel frame with a centre strut and robust loading forks.
hand stacker 1,2m image 19

Parking brakes

Mechanical brakes on both steering wheels ensure a secure stand without rolling away. Standard foot protection on the steering wheels protects feet from injury.
LIFT-M

Tubular push bars

Two large tubular push bars on the frame at hand height help when steering, pushing and manoeuvring the hand stacker.
manual stacker 1,6m image 9

Protective grating

A metal grating in a steel frame protects against falling objects without obstructing the view.

Technical data

General
Capacity
1000 kg
Weight
214 kg
Material
steel
Chassis surface
powder coated
Colour
Blue
Seal
CE
Warranty
5 years warranty Basic
SKU
10000902-82
Brand
Pallit
Wheels
Wheels material
Polyurethane (PU)
Steering wheel diameter
145 mm
Steering wheel width
40 mm
Fork roller type
tandem
Load roller wheel diameter
80 mm
Fork roller width
60 mm
Lift
Lift height
1600 mm
Max. lowering when loaded
3.25 mm
Free lift
yes
Free lift height
1600 mm
Lift height per full stroke
20 mm
Mast type
Simply
Lift type
manual hydraulic
Drive
Drive
manual
Delivery
Delivery
forwarding agency
Delivered as
rolling (fully assembled)
Links
Load center diagram
Product brochure
Product manual

Dimensions

  • Capacity
    Fork length
    Free lift height
    Height, lowered
    Lift height
    Weight
    Wheels material
    Fork roller type
    Load centre
    Warranty
    Free delivery
    Customer Reviews
    Price

  • Manual Stacker LIFT-M for 1,6m

    1000 kg
    1150 mm
    1600 mm
    1970 mm
    1600 mm
    214 kg
    Polyurethane (PU)
    tandem
    600 mm
    5 years warranty Basic
    Wednesday, 19 March
    from 1.139 € 1.366,80 € including 20% VAT
    from 1.199,00 €
